Physical Characteristics
Dimensions:		170mm x 95mm x 70mm
Weight:		162.2g
Voltage :		5VDC
Current :		80mA (standby); 300mA (Operating)
Performance Characteristics
Image (Pixels):		640 pixels (H)x 480 pixels (V)
光源Light Source:		Aiming: 617 nm LED; illumination: 6500K LED
Field of View:		45° (H) x 35° (V)
Roll / Pitch / Yaw:		360°, ±65°, ±60°
Print Contrast:		25% minimum reflective difference
Interfaces Supported:		USB, RS232
Motion Tolerances		up to 25 in. (63.5 cm) per second
Minimal Resolution:
Symbology Decode Capability	1D:	UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
	2D:	PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.
User Environment
Operating Temperature		0°C to 50°C
Storage Temperature:		-40°C to 70°C
Humidity:		0% to 95% relative humidity, non-condensing
Shock Specifications:		Designed to withstand 1.5m(5') drops
Ambient Light Immunity:		100.000 Lux.
Decode Ranges
5MIL		20mm-70mm
13MIL		40mm-160mm
1D Minimal Resolution		4mil

SuperLead 1D/2D Barcode Scanner Handheld Bar Code USB Wire Reader 2M USB Cable
